VEILUX HIGH-SPEED PTZ DOME 24 VOLT 550 TV LINES(18X ZOOM 12X Digital 216X with optical Zoom)

HIGH-SPEED DOME (18X ZOOM / 540 TVL)

View larger image

HIGH-SPEED DOME (18X ZOOM / 540 TVL)

Model Number: VP-F18X

Access to prices is restricted More Info

Restricted Access
  • 1/4" Sony ExView HAD Progressive Scan
  • 550 TV Lines Resolution
  • High Resolution, Sensitivity and Chroma Luminance
  • Preset, Auto Cruise & Pattern Scan Function
  • RS-485 Control
  • Multi Communication Protocol Supported, Baud Rate Programmable
  • 360º Continuous Pan, 0º~90º Tilt from a Horizontal Plane, Auto Flip 180º
  • Iris & Focus in either Manual or Auto Mode
  • Minimum Illumination: 0.01 Lux
  • Automatic Gain Control, Auto/Manual
  • White Balance, Auto/Manual
  • Backlight Compensation, Auto/Manual
  • 24VAC Power Supply
  • Weatherproof (IP-66) - (Outdoor Only)
  • Suitable Indoor, Surface and Outdoor Mount

 ITEM

VP-F18X

Mounting Type

Surface, In-Ceiling, Wall, Pole, Pendant

Signal System

NTSC

PAL

Image Sensor

1/4” ExVeiw HAD Progressive Scan

Resolution

550 TV Lines

Pan / Tilt Speed

Pan: 0.05°~400°/sec; Tilt: 0.03°~240°/sec

S/N Ratio

More than 50db (AGC OFF)

Min. illumination

0.7 Lux - Day

Gain Control

Auto / Manual

Back Light Compensation

Auto/Manual

Optical Zoom

18x

Digital Zoom

12x

Lens

F1.4-F3.0 f=4.1-73.8mm

Panning Range

Pan: 0°~360° ; Tilt: 0°~90°

Preset Position No.

256

Auto Cruise

Auto Swithch from 0 to 54 preset pos’ sequentially

Pattern Scan

P/T/Z scan from 55 to 63 preset pos’ automatically

Comm. Port

RS-485

Baud Rate

1200bps, 2400bps, 4800bps, 9600bps, 19200bps

Spectra Address

0~255

Power Supply

24VAC

Operating Temp’

-25°C ~ 70°C

?
Security Camera Features

?
  • 540 540
TVL
?
  • Sony Color  Sony Color
?
  • 18x Optical Zoom 18x Optical Zoom
mm
?
  • .01 Lux .01 Lux
LUX
?
  • 24VAC 24VAC
None

VP-F18X Specs Sheet (VP-F18X.pdf, 2,057 Kb) [Download]

VP-F18X User manual (NEW%20MANUAL%20tracking%2011-15-11.pdf, 1,927 Kb) [Download]
