SVEX-231-Z 23-Inch Explosion-Proof Industrial Monitor
The SVEX-231-Z is a 23-inch explosion-proof industrial monitor certified for Class I Division 1 and ATEX Zone 1 classified areas, enabling direct CCTV, SCADA, and process video display within oil and gas, chemical, pharmaceutical, and offshore hazardous environments. Built in 316L stainless steel with IP66 ingress protection, it provides field operators real-time visual access to surveillance and process data without leaving the hazardous zone.
Certifications and Hazardous Area Ratings
| Certification | Standard | Rating |
|---|---|---|
| UL / cUL Listed | UL 1203 | Class I, Division 1, Groups B, C, D |
| ATEX Certified | EN 60079-1 | II 2G Ex d IIC T4 Gb |
| IECEx Certified | IEC 60079-1 | Ex d IIC T4 Gb |
| Ingress Protection | IEC 60529 | IP66 |
| Impact Resistance | IEC 62262 | IK10 |
| Housing Material | – | 316L Marine-Grade Stainless Steel |
| Temperature Class | IEC 60079-0 | T4 (135 degrees C max surface) |
| Operating Temperature | – | -20 degrees C to +50 degrees C |
Display and Interface Specifications
| Parameter | Specification |
|---|---|
| Screen Size | 23 inches diagonal |
| Display Type | IPS LCD, Full HD (1920×1080) |
| Brightness | 400 cd/m2 (sunlight-readable option available) |
| Viewing Angle | 178 degrees H / 178 degrees V (IPS panel) |
| Video Inputs | HDMI, VGA, Composite (BNC) |
| Touchscreen | Optional resistive or capacitive overlay |
| Housing Material | 316L Stainless Steel |
| Mounting | Panel mount, wall mount, VESA 100×100 |
| Power | 100-240V AC, 50/60Hz |
Where Explosion-Proof Monitors Are Required
- Oil and Gas Refineries – Control operator stations within Class I Division 1 process areas
- Offshore Platforms – Drill deck, production deck, and wellhead control stations requiring ATEX Zone 1
- Chemical Plants – Classified reactor control rooms and field operator workstations
- LNG Terminals – Loading dock field control stations requiring real-time CCTV access
- Pharmaceutical Manufacturing – Classified solvent suite process monitoring stations
- Pipeline Compression Stations – Field monitoring of compressor controls and SCADA displays
Frequently Asked Questions
Is the SVEX-231-Z rated for Class I Division 1?
Yes. The SVEX-231-Z is UL listed and ATEX/IECEx certified for Class I Division 1 and ATEX Zone 1 classified areas. It allows operators to view live CCTV feeds, SCADA, and process video directly within hazardous zones.
What video inputs does it support?
HDMI, VGA, and composite (BNC) video inputs, enabling connection to NVRs, DVRs, workstations, and direct camera outputs. Compatible with both IP and analog CCTV systems.
Why install a monitor inside a hazardous area?
Field operators in classified areas need real-time visual access to surveillance feeds, process cameras, and SCADA displays without leaving the hazardous zone. An explosion-proof monitor improves operational efficiency and emergency response time by eliminating trips to safe area control rooms.
Is touchscreen operation available?
Yes. Optional explosion-proof resistive or capacitive touchscreen overlay enables interaction with SCADA systems, VMS interfaces, and process control displays from within Class I Division 1 and ATEX Zone 1 classified areas.
