EYS Fitting Selection Guide by Conduit Trade Size
[rank_math_toc]Explosion-proof conduit seals eys fittings installation for Hazardous Locations
| Conduit Size | Crouse-Hinds EYS | Appleton EY | Min Fill Depth |
|---|---|---|---|
| 1/2 in. | EYS12 | EY12 | 1/2 in. |
| 3/4 in. | EYS17 | EY17 | 1/2 in. |
| 1 in. | EYS22 | EY22 | 3/4 in. |
| 1-1/4 in. | EYS27 | EY27 | 1 in. |
| 1-1/2 in. | EYS32 | EY32 | 1 in. |
| 2 in. | EYS42 | EY42 | 1-1/4 in. |
| 2-1/2 in. | EYS53 | EY53 | 1-1/2 in. |
| 3 in. | EYS63 | EY63 | 2 in. |
Step-by-Step EYS Seal Installation
- Select correct fitting: Choose EYS for standard; EYD (drain-type) for outdoor or wet locations.
- Install within 18 inches: Thread EYS onto conduit within 18 inches of the explosion-proof enclosure. No fittings between seal and enclosure.
- Pack fiber dam: Insert Chico X fiber loosely to conduit-diameter depth inside the fitting body — prevents liquid Chico A from flowing into conduit.
- Mix Chico A: Mix powder with water at manufacturer ratio. Use within 5 minutes of mixing.
- Fill completely: Pour Chico A into the fitting to the minimum fill depth with no voids.
- Allow 24-hour cure: Do not energize or stress the fitting during curing at 70 deg F.
- Install fill plug: Thread and tighten the fill plug to complete the explosion-proof rating.
Common Installation Mistakes
The four most common conduit seal violations found by inspectors: (1) installing a coupling between the EYS seal and the explosion-proof enclosure — NEC 501.15 prohibits any fitting in this space; (2) insufficient Chico A fill depth leaving voids; (3) omitting the fiber dam, causing Chico A to distribute throughout the conduit run; (4) using non-listed sealing compound instead of Chico A or equivalent listed material.See also: NEC Article 501 Wiring Guide | Grounding and Bonding GuideFrequently Asked Questions
What is the maximum distance an EYS seal can be from an explosion-proof enclosure?
NEC 501.15(A)(1) requires the seal within 18 inches of the explosion-proof enclosure for conduit 3/4 in. and larger. No fitting of any type may be installed between the seal and the enclosure. For conduit smaller than 3/4 in., a seal is still required as close as practicable.What is Chico X fiber dam material used for?
Chico X fiber is packed into the conduit end inside the EYS fitting before adding Chico A compound. The fiber creates a physical barrier preventing liquid Chico A from flowing into the conduit run. Without the fiber dam, compound distributes throughout the conduit rather than forming a localized seal.Can EYS fittings be used in Division 2 as well as Division 1?
Yes. EYS fittings listed for Class I Division 1 Groups A-D are acceptable in Division 2 locations as well. Division 1 listed fittings satisfy Division 2 requirements. Division 2 requires seals only at boundaries between classified and unclassified areas, not within 18 inches of every enclosure.How long does Chico A take to cure?
Approximately 24 hours at 70 deg F (21 deg C). At 40 deg F, allow 48-72 hours. Use Chico FS (freeze-resistant) compound for cold weather installations below 32 deg F.What is the difference between EYS and EYD fittings?
EYD includes a 1/4 in. NPT drain plug at the bottom for draining moisture from the conduit. Both have identical sealing function and UL listing. EYD is recommended for outdoor, below-grade, or wet locations. Need explosion-proof cameras or explosion-proof conduit seals EYS fittings installation guidance? Request a quote from Veilux — full NEC/ATEX documentation included.Standards References: IECEx International Certification Scheme · OSHA Hazardous Work EnvironmentsExplore Veilux’s full range of explosion-proof cameras and request a quote for your hazardous-area project.A practical field rule for explosion-proof conduit seals EYS fittings installation: always fill and allow EYS sealing compound to cure before pulling wire through adjacent unsealed sections. Sealing compound shrinks slightly as it cures — verify fill level after 24 hours and top up if needed to maintain the full duct-seal depth required by the fitting manufacturer.Related Resources
