For any project involving explosion-proof or intrinsically safe equipment, three certification frameworks dominate global specification: ATEX (European Union), IECEx (international), and NEC/UL (North America). Understanding ATEX vs IECEx vs NEC is essential for procurement teams, HSE managers, and project engineers sourcing equipment across multiple markets or operating facilities on more than one continent.
ATEX: The European Union Standard
ATEX derives its name from the French ATmospheres EXplosibles and encompasses two EU Directives: ATEX 114 (Directive 2014/34/EU) governing equipment, and ATEX 153 (Directive 1999/92/EC) governing workplace health and safety in explosive atmospheres. ATEX certification is mandatory for equipment placed on the EU market or used in EU member states. Testing and certification are performed by EU Notified Bodies—third-party laboratories approved by EU member governments.
Equipment certified under ATEX carries markings such as II 2 G Ex d IIC T6 Gb. The Roman numeral group (I for mining, II for surface), category (1G, 2G, 3G for gas; 1D, 2D, 3D for dust), and temperature class are all specified. ATEX is legally recognized across all 27 EU member states plus Norway, Iceland, and Liechtenstein.
IECEx: The International Scheme
IECEx (IEC System for Certification to Standards Relating to Equipment for Use in Explosive Atmospheres) is a voluntary international certification scheme administered by the International Electrotechnical Commission. IECEx is accepted in over 40 countries and is widely recognized as the basis for mutual recognition agreements between national certification bodies.
An IECEx Certificate of Conformity (CoC) demonstrates that equipment was tested against the IEC 60079 series of standards—the same technical standards underlying ATEX. A key IECEx advantage is portability: many national schemes in Australia, South Africa, and other countries automatically recognize IECEx CoCs, reducing duplication when equipment crosses borders. Markings follow the form Ex d IIC T6 Gb without the EU-specific group numeral.
NEC / UL: North American Classification
The National Electrical Code (NEC), published by NFPA, governs hazardous area electrical installations in the United States and heavily influences Canadian Electrical Code requirements. Rather than the European zone system, NEC uses a Class and Division structure: Class I (flammable gases/vapors), Class II (combustible dusts), Class III (ignitable fibers), each divided into Division 1 (normally explosive) and Division 2 (abnormally explosive).
UL (Underwriters Laboratories) and FM Approvals are the primary testing bodies for NEC-based certification in North America. Equipment carries markings like Class I Division 1 Groups A, B, C, D T6. NEC also incorporates the IEC zone system (Zone 0, 1, 2) in Article 505, giving engineers a parallel path to specify zone-classified equipment in North American installations.
ATEX vs IECEx vs NEC: Side-by-Side Comparison
| Factor | ATEX | IECEx | NEC/UL |
|---|---|---|---|
| Geographic scope | EU mandatory | International (40+ countries) | USA/Canada primarily |
| Legal basis | EU Directive 2014/34/EU | Voluntary IEC scheme | NFPA 70 (NEC) statutory adoption |
| Technical standards | EN 60079 series | IEC 60079 series | UL 1203, ANSI/ISA 60079 |
| Certification bodies | EU Notified Bodies | IECEx ExCBs | UL, FM, CSA, Intertek |
| Hazard classification | Zone 0/1/2 (gas), Zone 20/21/22 (dust) | Same as ATEX | Class I-III, Division 1 and 2; also Article 505 zones |
| Mutual recognition | With IECEx via some Notified Bodies | Widest international recognition | Limited outside North America |
Can ATEX and IECEx Be Used Together?
When determining whether you need ATEX vs IECEx vs NEC certification, it’s important to look at where the equipment will be located. Many equipment manufacturers hold both ATEX and IECEx certificates for the same product, which is common practice for globally deployed equipment. ATEX and IECEx share the same underlying IEC 60079 test standards, so dual certification requires relatively little additional work—primarily separate documentation and review by the respective certification bodies.
For NEC projects in the USA, ATEX or IECEx certificates alone are not sufficient. UL or FM listing is required for code compliance under NEC Article 500/501. However, some jurisdictions accept IECEx CoCs as supporting documentation in variance applications. Veilux products carry dual ATEX/IECEx and UL/cUL listing, providing a single SKU for global procurement across ATEX vs IECEx vs NEC regulated markets.
Veilux Dual-Certified Equipment
All Veilux explosion-proof cameras carry both ATEX/IECEx certification and UL Class I Division 1 listing, making them compliant for EU, international, and North American projects from the same product line. Our explosion-proof PTZ cameras and explosion-proof lighting follow the same dual-certification approach, eliminating separate procurement for different regional projects.
Contact our team to receive certification documentation packages including ATEX/IECEx certificates and UL listings for your HAZOP or engineering review. Not sure which rating your equipment needs? We can help you figure out ATEX vs IECEx vs NEC certifications for your specific site.
ATEX vs IECEx vs NEC: Related Reading
- Intrinsically Safe vs Explosion-Proof Cameras: Key Differences
- Zone 1 vs Division 1: ATEX and NEC Classification Compared
- Hazardous Area Classification: Complete Guide
For the full text of IECEx certification requirements, visit IECEx.com for official scheme documentation and certificate search.
